| Business Type | Manufacturer, Exporter |
| Brand Name | Boost |
| Color | Green |
| Design | Standard |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Condition
New
Application
Industrial
Size
24 mm X 78 mm X 53 mm
Voltage
230 V AC
Warranty
1Year
Country of Origin
India
Operating Temperature
0 to 50 Degree Celsius
Storage Temperature
-10 to 60 Degree Celsius
Relative Humidity
5 to 85% RH
Relay On Indication
Green Color LED
Designation
Designation Plate Screwed to the Pcb for Labeling Purpose
No of Relay Channel
1 Channel
Rating of Contacts
10A at 30V DC and 250V AC for resistive load.
Coil Resistance
26,850 Ohms + 10%.
Input Current/ Channel
9 mA per channel
Mechanical Dimensions
24 mm X 78 mm X 53 mm
Delivery Time
1 week
Packaging Details
In Corrugated box with bubble sheet
Description
- Din Rail Mounting.
- Solderable Relay.
- 10,000,000 Mechanical operations minimum.
- 100,000 Electrical operations minimum.
Looking for "Relay Interfacing Module RP230A01-1CO-M" ?
