| Business Type | Manufacturer, Exporter |
| Brand Name | RP24D08-2CO-M-B8/P |
| Current Type | DC |
| Shape | Rectangular |
| Click to view more | |
Product Details
Color
Green
Condition
New
Application
Industrial
Size
182 Mm X 90 Mm X 68 Mm
Certification
CE Certified, ISI Certified
Feature
Accuracy, Durable, Heat Resistance, High Performance, Shocked Proof, Stable Performance
Packaging Type
In Corrufated Box With Bubble Sheet
Type
Relay Card
Theory
182 Mm X 90 Mm X 68 Mm
Frequency
50Hz, 60Hz
Channels
8
Warranty
1Year
Country of Origin
India
Temperature
0 To 50 Degree Celsius
No of Relay Channel
08 Channels
Rating of Contacts
5 Amp at 30 V DC & 250 V AC for Resistive load.
Coil Resistance
1440 Ohms +/-10%
Voltage
24 V DC
Relay Socket
Rating- 5 A, 250 V AC
Input Current/ Channel
17 mA @ 24 V DC
Relay Make / Manufacturer
OMRON
Relay Type
G2RL-2, Electro-mechanical
Contact Type
2 Change Over
Product Code
RP24D08-2CO-M-B8/P
Delivery Time
1 week
Packaging Details
In corrugated box with bubble box
Din Rail Mounting Pluggable Relay 20,000,000 Mechanical operations minimum. |
50,000Electrical operations minimum. |
