16 Channel DI Interface Slim Relay Module
| Business Type | Manufacturer, Supplier |
| Type No. | RP24D16DI-1NO-B5/P-SLM |
| Operating Temperature | 0 to 60 Degree Celsius |
| Storage Temperature | -10 to 60 Degree Celsius |
| Click to view more | |
Preferred Buyer From
| Location | Anywhere in India |
Product Details
Relative Humidity
5 to 90% RH
Relay ON Indication
Green Color LED
Relay Protection Method
Freewheeling Diode
Designation
Designation Plate Screwed to the Pcbfor Labeling Purpose.
Mechanical Dimensions
134 mm X 126 mm X 70 mm
Input Current/ Channel
7 mA
Relay Socket
6 A, 250 Volt AC
Coil Voltage
24 V DC
Coil Resistance
3,390 Ohms +/-10%
Rating of Contacts
6 A at 230 Volt AC
No of Relay Channel
16
Brand Name
Boost
Details:
- Din Rail Mounting
- Pluggable Relay
- 10,000,000 Mechanical operations minimum
- 60,000 Electrical operations minimum.
